Elumatec DG 104/02 CNC Double End Mitre Cut-off Saw, 2005

Bed Length: 4,500mm/177″
Minimum Cutting Length at 90°: 13.7795″
Minimum Cutting Length Tilted at 45°: 13.7795″
Pivoting Range Inwards: 90° – 45°
(Up To 22.5° Manual with Digital Display)
Tilting Range Inwards: Pneumatically 90° – 45°
Saw Blade Diameter: 16.5354″
Saw Blade Speed: 2,800 Rpm
Power Supply: 230/400 V, 3~, 50 Hz
Power Output Per Motor: 4 Kw
Compressed Air Supply: 7 Bar
Air Consumption Per Working Cycle: 40 Without Spraying, 64 with Spraying
