Mazak SQT-18MS CNC Lathe, 1997 – Live Tooling, Sub Spindle, Under Power

$29,900.00

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Multi Axis Lathes
Make: Mazak
Model: SQT-18MS
Year: 1997
Machine Location: California
Stock #: 849854

Max. Swing: 20.90″
Swing Over Carriage: 15.74″
Max. Machining Diameter: 11.75″
Max. Distance Between Spindles: 34.25″
Max. Bar Work Diameter: 2.51″
X-Axis Stroke: 7.125″
Z-Axis Stroke: 22.75″
Speed: 35 ~ 4000 RPM
Number of Spindle Speed Ranges: Stepless
Spindle Nose: A2-6
Spindle Bore: 2.99″
Min. Spindle Indexing Increment: 0.001″
Second Spindle Speed: 180 ~ 4000 RPM
Second Headstock Stroke: 23.25″
Second Headstock Rapid Traverse Rate: 708 IPM
Turret Type: Dodecagonal Drum
Turret Tool Capacity: 12 Tool Total
Tool Shank Height: 1.00″
Boring Bar Shank Diameter: 1.50″
Turret Indexing Time (Chip-to-chip): 1.6 sec/step
Rotary Tool Spindle Speed: 120 ~ 3000 RPM
Rapid Traverse Rate (X,Z): 1180 IPM
Jog Feedrate (X,Z): 0.04 ~ 78.74 IPM
1st spindle Motor (30 min / continuous rating): 25 / 20 HP
2nd spindle motor (10 min. rating): 10 HP
Rotary Tool Motor: 10 min rating
Coolant Pump Motor: 0.25 HP
Electric Power Source (30 min / Continuous rating): 48.8 kVA / 38.6 kVA
Air Supply: 71 PSI / 3.53 Ft /Min
Coolant Tank Capacity: 52.8 Gallons
Machine Height: 80.3″
Floor Space Requirement: 124.4″ x 63.4″
Machine Weight: 12,500 Lbs
Mazatrol T-Plus Control

Equipped with:
Sub-Spindle
Live Tooling
Full C-Axis on Main Spindle
C-Axis on Sub-Spindle
Maximum memory capacity
Automatic door
Parts Catcher
Chip Conveyor

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
