ScriptPro CRS 150 Prescription Dispensing System, 2024

Weight: 1,010 lbs (459 kg)

Robot Footprint: 9.5 sq ft (0.88 m2)

Electrical Input: 100-127 VAC ±10%, 50/60 Hz, 6 AMP, 1 Phase

Communications: Ethernet pharmacy computer connection

Remote Support Requirements: VPN over high-speed Internet connection.

Barcode Scanner: CCD Scanner

Computer/Software: Intel Six-Core i5C6 with 2 SSDs (500 GB each) and 16 GB RAM. TCP/IP socket connections; USB connections; software built with Visual C++; Windows 11/SQL 2022 Express Edition. Redundant data and transaction log backups.

Customer access limited to SP Central user interface.

Monitor: 17″ touchscreen with tilt mount

Environmental:

Operating: 41°F to 86°F (5°C to 30°C)
Storage: 5°F to 104°F (-15°C to 40°C)
Relative Humidity: 20-85%
Altitude: Up to 6,561 ft (2,000 m)
Dissipated Heat: 1,000 BTU/h
Pollution Degree: 2
Indoor Use Only

Cell Capacity:

Single Cell: 676 cc/183 dram
Extended Cell: 1,900 cc/514 dram
High Capacity Cell: 2,500 cc/676 dram

System Vial Staging Area: Maximum capacity on outfeed conveyor is 27 vials.

ANSI Barcode Print Quality Grade: B

Sound Level: 71 db

Regulatory: CRS 150

Product Lines: Robotics, WMS, PMS
