Vision Wide SF-4122 Bridge Mill, 87″ x 161″ Table, 2023 – “NEW” Condition Never Used

$300,000.00

Vision Wide SF-4122 Bridge Mill, 87" x 161" Table, 2023 - "NEW" Condition Never Used
Vision Wide SF-4122 Bridge Mill, 87" x 161" Table, 2023 - "NEW" Condition Never Used
Vision Wide SF-4122 Bridge Mill, 87" x 161" Table, 2023 - "NEW" Condition Never Used
Vision Wide SF-4122 Bridge Mill, 87" x 161" Table, 2023 - "NEW" Condition Never Used

Request a Quote to Instantly See Pricing

Call Now

Machine Type: Gantry/Bridge Mills
Make:
Model:
Year:
Machine Location:
Stock #:

Y Axis Travel: 86.7″
X Axis Travel: 161.4″
Z Axis Travel: 40″
Spindle Motor: 35 HP
Spindle Speed: 6,000 RPM
Spindle Taper: CAT 50
Tool Changer: 40 ATC
Rapid Rate X Axis: 787 IPM
Rapid Rate Y Axis: 787 IPM
Rapid Rate Z Axis: 590 IPM
Dimensions: 455″ x 205″ x 170″
Weight: 70,400 LBS
Max Table Load: 28,600 LBS
Options:
Fanuc OiMF
Probe = Renishaw RTS/RMP40 Probing System
Chip Conveyor
Coolant Thru Spindle
300 PSI Coolant Thru Spindle
Thru Spindle Air Blast
Dual Augers and Chip Conveyor
Box Ways In Z Axis
Never Used

All specifications are assumed to be correct but must be confirmed by the purchasing entity.
