Weeke BP 140 CNC Router Machining Center, 2000
$5,900.00
Request a Quote to Instantly See Pricing
Machine Type: Woodworking
Make: Weeke
Model: BP 140
Year: 2000
Capacity: ” ร
Machine Location: Texas
Stock #: 238317
X-Axis: 110.25″
Y-Axis: 41.34″
X-Axis Stroke: 146″
Y-Axis Stroke: 52″
Z-Axis Stroke: 10.24″
Rapid Traverse Speeds
X-Axis: 263 FPM
Y-Axis: 196 FPM
Z-Axis: 64 FPM
Work Table: 51″x125″
8 Panel Support Benches
Boring unit
Motor: 2 hp/1.5kW
4,000 RPM
Independent Vertical Spindles: 10 X-Axis, 10 Y-Axis, 1 Offset for 1.38″ Diameter Drills
1 Independent 4-Way Horizontal Boring Block with 6 Spindles
Routing:
10 HP High Speed Vertical Electro-Spindle
HSK F63 Adaptor Router
11 KVA Frequency Inverter
Programmable Speeds: 1,000-18,000 RPM
Elect./Voltage: 230/460 V
60 Cy.
3 Phase
All specifications are assumed to be correct but must be confirmed by the purchasing entity.
