Haas DS-30Y Dual Spindle CNC Lathe, 2020 – Live Tooling, Parts Catcher, Tool Presetter – Used For Testing Only – Never Ran Production
$124,900.00
This specific product is no longer available, however we may have other similar or identical products in stock. Please utilize our search function at the top of the page to check and confirm, or fill out the form below:
Max Cutting Diameter: 16″
Max Cutting Length: 23″
Distance Between Centers: 30″
Swing Over Bed: 31.75″
X-Axis Travel: 12.5″
Y-Axis Travel: ±2.0″
Z-Axis Travel: 23″
Main Spindle Motor: 30 HP
Main Spindle Speed: 4500 RPM
Spindle Nose: A2-6
Spindle Bore: 3.0″
Chuck Size: 10″
Secondary Spindle Motor: 20 HP
Secondary Spindle Speed: 4800 RPM
Secondary Spindle Nose: A2-5
Bar Capacity: 2″
Turret: 24 Stations
Equipped With:
Haas CNC Control
Y Axis
1 GB Memory
Macros
6,000 RPM Live Tooling Upgrade
4000 RPM Spindle with C Axis
24-station (half-index) BMT65 Turret
Automatic Tool Presetter
Chip Conveyor
Enclosure Exhaust System
High Intensity Lighting
Parts Catcher System
Early Power Failure Detection Module
Ethernet Interface
Haas Connect
Rigid Tapping
Spindle Orientation
M-Code
CNC Control Cabinet Cooler
